| Nguồn gốc: | Trung Quốc |
|---|---|
| Hàng hiệu: | SAFEGAS |
| Chứng nhận: | ATEX/IECEX |
| Số mô hình: | SG100 |
| Số lượng đặt hàng tối thiểu: | 1 |
| Giá bán: | có thể đàm phán |
| chi tiết đóng gói: | Đóng gói vali nhôm |
| Thời gian giao hàng: | 3-5 ngày làm việc |
| Điều khoản thanh toán: | T/T, Liên minh phương Tây |
| Khả năng cung cấp: | 100 mảnh/ngày |
| Khí được phát hiện: | Khí độc, oxy, khí dễ cháy, khí VOC | Nguyên tắc phát hiện: | Điện hóa, NDIR, Xúc tác, PID, v.v. |
|---|---|---|---|
| Đo phạm vi: | Chỉ định theo ứng dụng | Nghị quyết: | Chỉ định theo ứng dụng |
| Sự chính xác: | ≤±2-5%FS (Tùy thuộc vào cảm biến cụ thể) | Lớp chống nổ: | IECEX: Ex ATEX: Ex DB IIC T6 GB, Ex |
| Lớp bảo vệ: | IP66/68 | ||
| Làm nổi bật: | IECEx ATEX certified gas detector,intrinsically safe toxic gas detector,fixed multi gas detector |
||
| Gas Detected | Toxic gases, oxygen, flammable, VOC gases |
|---|---|
| Detection Principle | Electrochemical, NDIR, Catalytic, PID, etc |
| Measure range | Specified according to application |
| Resolution | Specified according to application |
| Accuracy | ≤±2-5%FS (Depending on the specific sensor) |
| Explosion-proof grade | IECEx: Ex db IIC T6 Gb, Ex db ia IIC T6 Gb; ATEX: Ex db IIC T6 Gb, Ex db ia IIC T6 Gb |
| Protection grade | IP66/68 |
| Power dissipation | Toxic gas<2.5W, flammable gas<4W |
| Communication mode | 4-20mA (3-wires),RS485 1~5V, Hart (Optional) |
| Wireless | LORA, 4G (Optional) |
| Working voltage | 12-24VDC |
| Relay | 3 relays, including low/high/fault alarm relay (Optional) |
| Display | LED display |
| Working temperature | -40℃~70℃ (Catalytic sensor), -20℃~50℃ (Electrochemistry sensor) |
| Working pressure | 86kPa~106kPa |
| Casing material | Die casting aluminum, S316 for option |
| Cable Entries | 1 x ¾ NPT & 1 x M20 Cable Entry Connections |
| Size | 157.8×128.8×69.6mm |
| Weight | 1.0Kg |
| Warranty | 1 year |
Established in 2010, Shenzhen Yuante Technology Co., Limited is a company that focuses on the design, production and sales of high-end gas detection equipment and system for 16 years. With gas detector as the core product, we have completed production line and solutions according to different industries, such as Oil, Chemical, Medicine, Energy, Environmental Protection, Electronic,Municipal Engineering, Agriculture and Forestry, Household Appliances, etc. Through about 10 years of rapid development, Yuante becomes the influential supplier.
For years, Yuante always insists on the management concept Market is orientation; Innovation is motivation; Quality to survival; Development to growth. With friendly, open and strict corporate culture and standardized management, Yuante gathers a lot of talents, and builds up the management team and R&D team. All the staff cooperates well in product development, production and maintenance, and has a deep understanding of the concept of customer oriented and has the service spirit through the company operation and management, to win the trust and support from customers.
The essence of a detector is the accuracy and faster response. Depending on years of measurement experience and unique solutions, through independent research and development, cooperative development and learning overseas latest technology, Yuante's products are advanced beyond the domestic brands and ahead of the global brands. We are seeking for development and progress constantly, and trying to meet diversified demands from customers.
